The HY10K48V-1P-EU is a powerful single phase hybrid inverter designed to meet diverse energy needs.
Parallel operation with up to 9 Units
Programmable supply priority for PV, Battery or Grid
Programmable multiple operation modes
Built-in MPPT solar controller 100/120A
Direct plug Wifi dongle supported
Protection level: IP21
HY10K48V-1P-EU | |
Max PV Input Power | 12000w |
Rated Output Power | 10000w |
Max Charging Power | 10000w |
Phase | 2-Phase in/1-Phase out |
PV INPUT (DC） | |
Nominal DC Voltage /Max DC voltage | 550VDC/800VDC |
Start-up Voltage | 80VDC |
MPPT Voltage Range | 80VDC-8000VDC |
Number of MPPT /Max Input Current | 2/20A |
MPPT Efficiency | >99% |
GRID-TIE-OPERATION GRID-TIE OUTPUT (AC) | |
Nominal Output Voltage | 230VAC |
Output Voltage Range | 170-264VAC/90-264VAC |
Nominal Output Current | 45A |
Power Factor | >0.99 |
THDI | <3% |
EFFICIENCY | |
Max Conversion Efficiency (DC/AC) | 95%(Battery To AC)/98%(PV To AC) |
DFF-GRID, HYBRID OPERATION AC INTPUT | |
AC Start up Voltage / Auto Restart Voltage | 170VAC/180VAC |
Acceptable Input Voltage Range | 170-264VAC/90-264VAC |
Max AC Input Current | 45A |
BATTERY MODE OUTPUT (AC) | |
Nominal Output Voltage | 230VAC |
Output Rating Power | 10000w |
Surge Power | 15000W |
Transfer Time | <10ms |
Output Waveform | Pure sine wave |
THDV | <3% |
Efficiency(DC to AC) | 94% |
BATTERY&CHARGER | |
Nominal DC Voltage | 48VDC |
Max PV Charging Current | 220A |
Max AC Charging Current | 180A |
Max Charging Current | 220A |
GENERAL PHYSICAL | |
Dmmension,D*W*H(mm) | 120*480*700 |
Net Weight(kg) | 20 |
INTERFACE | |
Upper Comptter Communication Port | RS-485 |
WIFI / BMS Communication Port | RS-485 |
ENVIRONMENT | |
Humidity | 0-9%RH(Non-condensing) |
Operating Temperature | -10 to 50 |
