Colorful touch LCD, IP65 and IP21 Optional
AC couple to retroft existing solar system
Max. 16 pcs parallel for on-grid and off-grid
operation, Support multiple batteries paralle
Max. charging/discharging current of 190A
6 time periods for battery charging/discharging
Support storing energy from diesel generator
3KW-12KW ranges
Support diesel generator connection
Colorful touch LCD
Max. charging/discharging current of 120A/210A
Support Max. 16pcs parallel
IP65 protection degree
Support remote control/change settings without internet
MODEL | HY3.6K-1P-EU |
Battery Input Data | |
Battery Type | Lead-acid or Lithium-ion |
Battery Voltage Range (V) | |
Max. Charge/Discharge Current (A) | 90 |
Max. Charge/Discharge Power ( kW) | 3.96 |
Charge Curve | 3 Stages/Equalization |
Charge Strategy for Li-Ion Battery | Self-adaption to BMS |
PV String Input Data | |
Max.DC Input Power (W) | 7200 |
PV Input Voltage (V) | 100~500 |
MPPT Voltage Range (V) | 125~425 |
Full Load DC Voltage Range (V) | 240~425 |
Start-up Voltage (V) | 100 |
Max.PV Input Current/ISC PV (A) | 18+18 / 28+28 |
No.of MPPT Trackers/Number input strings | 2/1+1 |
AC Output Data | |
Rated AC Output and UPS Power (W） | 3600 |
Max.AC Output Apparent Power (VA) | 3960 |
Peak Power (off grid) | 1.5 times the rated power，10S |
AC Output Rated Current (A) | 15.7 |
Max.AC Current (A) | 18.0 |
Max.Continuous AC Passthrough (A) | 35 |
Power Factor Adjustment Range | 0.8 leading to 0.8 lagging |
Output Frequency and Voltage | 50/60Hz; 220/230 / 240Vac |
Grid Type | Single Phase |
Current Harmonic Distortion | THD<3% (Linear load<1.5%) |
Efficiency | |
Max.Efficiency/Euro Efficiency/MPPT Efficiency | 97.6%/97%/99.9% |
Equipment Protection | |
Integrated | PV Input Lightning Protection; Anti-islanding Protection; PV String Input Reverse Polarity Protection; Insulation Resistor Detection; Residual Current Monitoring Unit; Output Over Current Protection; Output Shorted Protection; Output Over Voltage Protection; DC circuit breaker. |
Surge protection | DC Type II/AC Type II |
General Data | |
Grid Regulation | IEC61727,IEC62116,IEC61683 |
Safety/EMC Standard | IEC62109-1,IEC62109-2/IEC61000-6-1,IEC61000-6-3 |
Operating Temperatur Range (℃)/Protection Degree/Cooling/Noise (dB) | -25~60℃,>45℃ Derating/IP65/Natural cooling/<30 dB |
Communication with BMS | RS485; CAN |
Weight (kg) | 20.5 |
Size (mm) | 330W×580H×232D |
Installation Style | Wall-mounted |
Warranty | 5 years |
Applications of Single Phase Hybrid Inverter:
Residential homes seeking energy independence and backup power.
Households aiming to reduce reliance on the grid and lower energy costs.
Small businesses and light-commercial operations with single-phase power supply.
Areas with time-of-use electricity pricing or an unstable grid.
Empower your home with Hootrum's reliable and intelligent energy solution. Our single-phase hybrid inverters are the key to a smarter, more resilient, and cost-effective energy future
