MAIN FEATURES
MPPT Solar Charge Controller Inside
Wide PVInput Range
Reliable quality, economic design
Smart battery protection.Compatible with LiFePo4
Configurable battery &AC/Solar priority via LCD setting
Only 1pcs 36V solar panel can start 1kva solar inverter
An ideal choice for any backup power inverter system, this unit integrates a high-efficiency MPPT Solar Charge Controller Inside, which is a cornerstone feature for a robust backup power inverter system.
TECHNICAL PARAMETER | |
Model | O1K-1P-EU |
The rated power | 1000VA/850W |
INPUT | |
Voltage | 230VAC |
Selectable Voltage Range | 170-280VAC(UPS),90-280VAC(Appliances) |
Frequency Range | 50Hz/60Hz (Auto sensing) |
OUTPUT | |
AC Voltage Regulation (Batt.Model) | 230VAC±5% |
Surge Power | 2000VA |
Power factor | 0.9 |
Efficiency(Peak) | >94% |
Transfer Time | 10ms(UPS),20ms(Appliances) |
Wave form | Pure sine wave |
No load current | <28W |
BATTERY | |
Battery voltage | 12VDC |
Low battery alarming voltage | 11.0VDC |
Low battery cut off protection voltage | 10.5VDC |
Low battery recovery voltage | 11.75VDC |
Floating Charge Voltage | 13.5VDC |
Overcharge Protection | 16.0VDC |
MPPT SOLAR CHARGER&AC CHARGER | |
Maximum PVArray Power | 600W |
MPPT Range Operation Vol | 20-150VDC |
Best PV range | 36-150V |
Maximum PVAray Open Circuit Vol. | 150VDC |
Maximum Charge Current | 80A |
Maximum MPPT Charge Current | 40A |
Maximum Efficiency | 98% |
BEST PANEL CONFIGUTATION | |
Maximum PVArray Power | 600W |
PHYSICAL | |
Products Dimension,D*W^H(mm) | 317mm*272mm*104mm |
Packing size,D*W*H(mm) | 370mm*328mm*160mm |
Net Weight (kgs) | 4KG |
G.W.kg | 4.8KG |
Communication Interface | RS232/GPRS/Optional WIFI |
OPERATING ENVIRONMENT | |
Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Operation Temperature | -10°℃-50℃ |
